Leave No Fingerprints: Survey-Grade Accuracy in an Era of Zero Disruption

A colorized LiDAR point cloud of the Cape Fear Memorial Bridge in Wilmington, North Carolina, showing the bridge’s vertical lift span, towers and surrounding structures captured as part of McKim & Creed’s survey-grade 3D model. Courtesy of McKim & Creed.

No lane closures. No overnight crews in reflective vests. No targets bolted to deck surfaces. No personnel standing on live structures. No disruption to the vessels passing underneath or the aircraft taxiing overhead. The infrastructure keeps operating exactly as it did before the survey team arrived and when they leave, the data is survey-grade, validated, and delivered.

Whether roadways, railways or airports, it is increasingly the standard that infrastructure owners demand, and it is driving a quiet but significant shift in how leading survey firms build their workflows. The question is no longer just Can you hit the accuracy spec? It is, Can you hit it without leaving a mark?

Civil engineering and surveying firm McKim & Creed has been methodically building toward an answer. The firm’s LiDAR group has developed a hybrid static-plus-mobile workflow that delivers survey-grade point clouds on operationally constrained infrastructure without the disruptions that traditional target-based methods require. The approach was pressure-tested on one of the more demanding structures imaginable: a four-lane, 1969-era vertical lift bridge over an active navigation channel in Wilmington, North Carolina.

Now it’s being carried into territory that makes the bridge project look straightforward.

McKim & Creed deployed static terrestrial LiDAR from safe positions near the Cape Fear Memorial Bridge while mobile LiDAR collected the bridge and approach corridors, enabling survey-grade data collection without lane closures or disruption to bridge operations. Courtesy of McKim & Creed.
